MODEL:XD-80S(1+1)
Main Characteristic :
Double Carriage with single cam system , this S-Series computerized flat knitting machine are used digital technology to achieve the patterns of knit ,transfer , tuck , pointel , intarsia , jacquard ,apparent shape, hidden shape , and other regular or irregular patterns knitting functions , can knit basic single or double jersey plain fabric , irregular multi-color jacquard , intarsia , cable and pointel structure patterns , which suitable to knit by yarns of pure silk ,mixed silk , synthetic , wool ,acrylic ,mixed fiber material etc. knitted for shaping fabric and accessories of collar , cardigan ,rib, cuff, scarf ,pocket and trousers etc.
| Knitting System: Single System | |||||||||
| Machine Speed: 1.4m/Second(Max), 32 section adjustable | |||||||||
| Knitting Function: Jacquard,Transfer,Miss,Intarsia,Hide，Pointel,Hide or Apparent Shaping And Other regular or Irregular Patterns. | |||||||||
| Stitch density: Controlled by 32 section electricity, density adjustment driven by stepping motor, range: 0-650 | |||||||||
| Racking: AC Servo Motor drive, the maximum racking within 2 inches | |||||||||
| Needle actuator: 8 section electronic needle actuator | |||||||||
| Roller System: Main and sub roller devices,32 section automatic control, subsection adjustable | |||||||||
| Yarn Carriers:2*6 yarn carriers are arranged on the left and right sides of the 3 double side guide rails. | |||||||||
| Transmission system: Belt drive, High precision AC servo motor control. | |||||||||
| Data input: Input and output patterns via USB, PC and Internet | |||||||||
| Protection system:Automatic stopping device if yarn broken, yarn knot, batching, striking, completion, overload, designated starting and stopping, program error | |||||||||
| Safety device:The whole machine cover to reduce noise and dust, the protecting cover is equipped with stopping sensor, emergency stopping and power off device | |||||||||
| Power: Voltage: AC 220V, Frequency: 50HZ/60HZ, Power:1.2KW | |||||||||
Length×width×height: 3650×900×1600mm Net weight :1000kg
