Model:HS252Pro
The Best Value For Money!
Single Carriage with double cam system , this HS-Series computerized flat knitting machine are used digital technology to achieve the patterns of knit ,transfer , tuck , pointel , intarsia , jacquard ,apparent shape, hidden shape , and other regular or irregular patterns knitting functions , can knit basic single or double jersey plain fabric , irregular multi-color jacquard , intarsia , cable and pointel structure patterns , which suitable to knit by yarns of pure silk ,mixed silk , synthetic , wool ,acrylic ,mixed fiber material etc. knitted for shaping fabric and accessories of collar , cardigan ,rib, cuff, scarf ,pocket and trousers etc.
| Gauge : | 3G,3.5G,5G,7G,8G,9G,10G,12G,14G,16G,3-5-7G multi-gauge | ||
| Knitting width : | 52,60,72,80inch | ||
| knitting function: | Knit ,miss,transfer,Tuck, pointel, intarsia,jacquard,hide,or apparent shaping and other regular or irregular patterns. | ||
| Knitting speed: | Controlled by sevro-motor with 32 sections optional, max speed reach 1.6M/S | ||
| Knitting system: | Single carriage with 2-system | ||
| Take down roller: | Computer programs instruction,stepper motor control and 32-stagetension selection with an adjustable range between 0-100 | ||
| Needle selection： | Advanced encoder reading pin.8-stage selecting needle setup composed of special electromagnet is regarded as efficient full width jacquard needle selector. | ||
Doubl System , single Carriage !
Length×width×height: 2650×900×1600mm Net weight :1090kg
